MITSUBISHI Laser

Mitsubishi Laser Consumables
Page 1 2 3 4 5 6







Reference numberDescriptionPkg / qty
1P0594-860-00001Nozzle holder – IT HP2 MZP/MEL1
2W390Double nozzle insert – 4 holes1
W270-6Double nozzle insert – 6 holes1
W270Double nozzle insert – 8 holes1
W387Double nozzle insert – 12 holes1
W388Double nozzle insert – 16 holes1
W389Double nozzle insert – 20 holes1
W515Double nozzle insert – 24 Holes1
371800027, BQ933D221H04, P0593-860-00001Shield cap – short1
Shield cap – short, chrome plated1
4W269Shield cap1
Shield cap chrome plated1
5Ring (plastic)1
6Nozzle – 1.7 mm (outer)1
Nozzle – 2.0 mm (outer)1
Nozzle – 2.5 mm (outer)1
Nozzle – 3.0 mm (outer)1
Nozzle – 4.0 mm (outer)1
7BQ933D04YH01Nozzle, outer – high speed pierce1
871800155TF, BQ023D021H01Insulation ring – PTFE*1
71800155AL, BQ023D021H01Insulation ring – aluminum1
971802197, BQ933D044H01Nozzle, outer1
107180015400, BQ023D020H01Nozzle – 1.7 mm high speed pierce1
11P0593-895-00001Nozzle holder – IT HP2" ZP/MEL1
Nozzle holder – IT HP2" ZP/MEL (OEM)1
1271800009, P921K000P25, JPZA5-6Safety pin1
1371800008, L249OA005Safety screw1
