MAZAK Laser

Mazak Laser Consumables
Page 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31







Reference numberDescriptionPkg / qty
146683301110Central copper body1
2Central copper body1

3

46683301080, 46683302081Spacer – 27x5.5 PTFE*1
46683301080, 46683302081Spacer 27x5.5 – plastic1
46683301080, 46683302081Spacer 27x5.5 – ceramic1
46683301080, 46683302081Spacer 27x5.5 – ceramic1
4J2600S03200O-ring external base – rubber1
546683301070Base – brass1
646683301090, 46683302091Spacer 30x4 – PTFE*1
46683301090, 46683302091Spacer 30x4 – plastic1
46683301090, 46683302091Spacer 30x4 – ceramic1
46683301090, 46683302091Spacer 30x4 – ceramic1
746683301100Nut – copper1
846773300510Nut – copper1
946683301120Spacer 24x3 – PTFE*1
46683301120Spacer 24x3 – plastic1
46683301120Spacer 24x3 – ceramic1
46683301120Spacer 24x3 – ceramic1
1046773300710Spacer 24x3 – ceramic1
46773300710Spacer 24x3 – ceramic1
1146683300850Nozzle holder – copper1
1246773300720Nozzle holder – copper1
1346683301130Spacer 24x4 – PTFE*1
46683301130Spacer 24x4 – plastic1
46683301130Spacer 24x4 – ceramic1
46683301130Spacer 24x4 – ceramic1
1446683301140Body – aluminum1
1546683301150Spacer 17x1.5 – PTFE*1
1646683301930Protection disk – PTFE*1
46683301930Protection disk – plastic1
46683301930Protection disk – ceramic1
1746683301841Spacer – PTFE*1
1846683301160Ring 17x2 – copper1
1946683301180Screw for contact1
2046683301170Contact1
21Connecting PTFE* pipe1
2246683300000Screw for connectors (4 pcs)4
23Connector1
2446683301170Kit connector (AL76,88,127,113)1
25Connector assembly1
2646683301830Adapter for Trumpf style nozzles1
27Please refer to the Trumpf nozzle section
28Please refer to the Mazak nozzle section
29Please refer to the Mazak nozzle section
