EASB Plasma

EASB PT-15/PT-15XL Nitrogen


System ESP-300, ESP-400, ESP-600 and ESP-1000 Consumables

Reference numberDescriptionPkg / qty
120759Nozzle retaining cap, PT-15XL1
20758Nozzle retaining cap, bevel, PT-15XL1
996230Nozzle retaining cap, PT-151
22075691Nozzle assembly, N, .125, 250 amp1
2075611Nozzle assembly, N, .156, 400 amp1
2075614Nozzle assembly, N, .156, reverse swirl1
2075612Nozzle assembly, N, .200, 600 amp1
2075615Nozzle assembly, N, .200, reverse swirl1
2075613Nozzle assembly, N, .230, 750 amp1
2075690Nozzle assembly, N, .230, reverse swirl1
2075587Nozzle assembly, N, .250, 875–1000 amp1
N/ANozzle base, 125 amp, PT-15XL1
N/ANozzle insulator, 125 amp, PT-15XL1
32075586Gas baffle, ceramic, 8 x .067, 260 amp1
948142Gas baffle, ceramic, 4 hole, 100–280 amp1
2075341Gas baffle, poly, 4 hole1
2075360Gas baffle, poly, reverse swirl, 4 hole1
4600236Electrode tip, N5


System ESP-300, ESP-400, ESP-600 and ESP-1000 Maintenance Items

Reference numberDescriptionPkg / qty
Reference numberDescriptionPkg qty
52075343Electrode tip holder, N1
621940Contact ring assembly1
20403PA bus insulator1
720755Insulator body with o-ring, PT-15XL1
996232Insulator body with o-ring, PT-151
820754Torch body, PT-15XL1
19483Double threaded mounting tube1
N/AO-ring kit, insulator body1
37110Electrode holder – removal tool1
N/ALubricant .25 oz. (7 ml) tube1
