EASB Plasma

ESAB PT-36 (m3 system)
Page 1 2


SilverLine electrodes and CoolFlow nozzles

System System: ESP-200/300/400/600C/1000, EPP-200, 360 Consumables

Reference numberDescriptionPkg / qty
137081Shield retainer, copper1
0558009395Shield retainer, plastic1
20558007624Shield, 2.4 mm, 45–55 amp1
0558006130Shield, 3.0 mm, 35–50 amp1
0558006141Shield, 4.1 mm, 100–280 amp1
0558006166Shield, 6.6 mm, 260–450 amp1
0558006199Shield, 9.9 mm, 360–600 amp1
21796Diffuser, 50 amp1
321944Diffuser, 100–600 amp1
22496Diffuser,100–600 amp, reverse1
4N/ANozzle retaining cap, quick-change1
537082Nozzle retaining cap1
60558006908CoolFlow nozzle, .08 mm, 35 amp1
0558008010CoolFlow nozzle, 1.0 mm, PR, 45–55 amp1
0558006010CoolFlow nozzle, 1.0 mm, 50 amp1
0558006014CoolFlow nozzle, 1.4 mm, 100 amp1
0558006018CoolFlow nozzle, 1.8 mm, 130 amp1
0558006020CoolFlow nozzle, 2.0 mm, 200 amp1
0558006023CoolFlow nozzle, 2.3 mm, 280 amp1
0558006025CoolFlow nozzle, 2.5 mm, 300 amp1
0558006030CoolFlow nozzle, 3.0 mm, 360 amp1
0558006036CoolFlow nozzle, 3.6 mm, 450 amp1
0558006041CoolFlow nozzle, 4.1 mm, 600 amp1
70558005459SilverLine electrode, O2, 45–90 amp1
80558003914SilverLine electrode, long life, 200-450 amp1
90558007791, 0558003914SilverLine electrode, O2, 260–450 amp1
100558012000, 0558003914SilverLine electrode, O2, 100–450 amp, XC1
0558003928Electrode, stainless steel/aluminum, 600 amp1
0558009548Shield retainer, XC1
0558010766Shield, 6.6 mm, XC1
0558009551Shield, 5.1 mm, XC1
0558009550Nozzle retaining cap, XC1
N/ANozzle retaining cap, quick-change, XC1
0558011619CoolFlow nozzle, 1.9 mm, 200 amp, XC1
0558010722CoolFlow nozzle, 2.2 mm, 260 amp, XC1
0558011625CoolFlow nozzle, 2.5 mm, 360 amp, XC1
0558006028CoolFlow nozzle, 2.8 mm, 450 amp, XC1

*C122-1014 electrode is not recommended for cutting below 200 amps or marking applications.
