Bystronic fiber laser

Bystronic fiber laser
Page 1 2 3 4





Esse A
part number
Reference number
Description		Pkg
qty

1		L306003-16058, NK10-15BY-Nozzle double, 1.0 mm (10 pk)*10
L306013-16059, NK12-15BY-Nozzle double, 1.25 mm (10 pk)*10
L306023-16060, NK15-15BY-Nozzle double, 1.5 mm (10 pk)*10
L306033-14317, NK17-15BY-Nozzle double, 1.75 mm (10 pk)*10
L30600X3-16058, NK10-15BY-Nozzle double, 1.0 mm CP (10 pk)*10
L30601X3-16059, NK12-15BY-Nozzle double, 1.25 mm CP (10 pk)*10
L30602X3-16060, NK15-15BY-Nozzle double, 1.5 mm CP (10 pk)*10
L30603X3-14317, NK17-15BY-Nozzle double, 1.75 mm CP (10 pk)*10

2		L30983-01894, 10BY-Nozzle, 1.0 mm (10 pk)*10
L30993-01895, 12BY-Nozzle, 1.25 mm (10 pk)*10
L301003-01896, 15BY-Nozzle, 1.5 mm (10 pk)*10
L301013-01897, 17BY-Nozzle, 1.75 mm (10 pk)*10
L301023-01898, 20BY-Nozzle, 2.0 mm (10 pk)*10
L306763-04272, 25BY-Nozzle, 2.5 mm (10 pk)*10
L306733-04275, H08BY-Nozzle HD, 0.8 mm (10 pk)*10
L30883-01899, H10BY-Nozzle HD, 1.0 mm (10 pk)*10
L301033-01900, H12BY-Nozzle HD, 1.25 mm (10 pk)*10
L301043-01901, H15BY-Nozzle HD, 1.5 mm (10 pk)*10
L301053-01902, H17BY-Nozzle HD, 1.75 mm (10 pk)*10
L301063-01903, H20BY-Nozzle HD, 2.0 mm (10 pk)*10
L306773-04276, H25BY-Nozzle HD, 2.5 mm (10 pk)*10
L30679H30BY-Nozzle HD, 3.0 mm (10 pk)*10
L3088X3-01899, H10BY-Nozzle HD, 1.0 mm CP (10 pk)*10
L30103X3-01900, H12BY-Nozzle HD, 1.25 mm CP (10 pk)*10
L30104X3-01901, H15BY-Nozzle HD, 1.5 mm CP (10 pk)*10
L30105X3-01902, H17BY-Nozzle HD, 1.75 mm CP (10 pk)*10
L30677X3-04276, H25BY-Nozzle HD, 2.5 mm CP (10 pk)*10
L30679XH30BY-Nozzle HD, 3.0 mm CP (10 pk)*10

3		L301251N12-15BY-Nozzle double, 1.25 mm (10 pk)*10
L301252N15-15BY-Nozzle double, 1.5 mm (10 pk)*10
L301253N17-15BY-Nozzle double, 1.75 mm (10 pk)*10
L301254N20-15BY-Nozzle double, 2.0 mm (10 pk)*10
L301255N25-15BY-Nozzle double, 2.5 mm (10 pk)*10
L301256N25-20BY-Nozzle double, 2.5 mm (10 pk)*10
L301257N30-17BY-Nozzle double, 3.0 mm (10 pk)*10
L301258N30-20BY-Nozzle double, 3.0 mm (10 pk)*10
4AL4187023207, 7023208BY-Water connector set1
5AL4167023207BY-Water connector, male1
6AL4177023208BY-Water connector, female1
*Available in single packs. To order single packs, remove the “X’ at the end of the part number (e.g. AM123-4567X would be AM123-4567).
