SilverLine 電極

系統: ESP-200/300/400/600C/1000, PCM-150/1500 維護項目

	型號	產品概述	包裝數量
15	0558001621	Electrode holder	1
16	37071	Contact ring 組件	1
	37073	螺絲, contact ring	1
17	N/A	Electrode holder mounting 螺母, PT-600
18	0558002533	Gas baffle, 4 x .032, 50–200A	1
	0558002534	Gas baffle, 4 x .032, 50–200A, reverse	1
	0558002530R, 35661	Gas baffle, 8 x .047, 250–600A, reverse	1
	0558001625	Gas baffle, 8 X .047, 300–600A	1
	22194	Gas baffle, 32 X .023, 400A	1
	996528	O型圈, 外絕緣體 本體和噴槍	5
	N/A	O型圈套件 絕緣體 本體	1
	19483	Double threaded mounting 真空管	1
	37083	絕緣環 本體 use with C47-066	1
19	0558001825	噴槍頭, quick-change	1
20	0558001825	噴槍底板, quick-change, PT-600	1
	0558001825	噴槍套件, quick-change, PT-600	1
21	0558001825	噴槍 本體 組件, modular, with 絕緣體	1
	N/A	I H S wire 組件 kit	1
	N/A	Bullet plug kit, quick-change 噴槍	1
	N/A	Insulating 真空管 kit, PT-19XLS/PT-600	1
	N/A	O型圈套件, bullet plugs	1
	N/A	O型圈套件, mounting 螺母	1
	N/A	O型圈套件, retaining cap	1
	0558004611	Electrode holder tool	1
	34775	Power cable, 4.5 ft.	1
	N/A	Lubricant .25 oz. (7 ml) 真空管	1

C96-6100 噴槍套件, PT-600/PT-19XLS quick-change includes:

	型號	產品概述	包裝數量
	0558001825	噴槍底板, quick-change, PT-600	1
	0558001825	噴槍頭, quick-change	1
	N/A	Electrode holder mounting 螺母	1
	0558001621	Electrode holder	1
	N/A	噴嘴 retaining cap	1
	21944	Diffuser, 100–600A	1
	N/A	O型圈套件, bullet plugs	1
	N/A	O型圈套件, mounting 螺母	1
	N/A	O型圈套件, retaining cap	1
	N/A	Lubricant .25 oz. (7 ml) 真空管	1
	N/A	Field service bulletin	1
